| Self-Propelled Scissor Lifts-GTZ1623D |
|
|
|
|
Product Description
- 1. Excellent performance: Superior to other scissor lifts, with better offroad performance and automatic levelling of outriggers.
2. Large load capacity: The maximal load capacity of the platform reaches 1499 lbs (680 kg); the extended platform can load500 lbs (227 kg), holding 6 operators at the same time.
3. Powerful driving force: The engine is of famous international brand, large in power.
4. Strong gradeability: The maximal gradeability is 40%; it can be parked and restarted on such slope without down sliding.
5. Advanced technology: Self-adaption floating device, fault self-diagnosis technology, self-levelling system, and anti-collision transducer option.
6. High reliability: The engine, key hydraulic components and electric components are all of international brand, designed in conformity with EN280, AS1418.10 and GB25849.
7. Good safety: The product is equipped with an emergency descending system, automatic engine abnormal shutdown function, overload limit and rollover protection system, which guarantees operator¡¯s safety.
8. Easy maintenance: Swing-out engine and overhead door, easy to maintain.
-
|
Model |
GTZ1623D |
|
|
Dimensions |
|
Platform height |
52 ft 9 in (16.1 m) |
|
Working height |
59 ft 4 in (18.1 m) |
|
Extended platform (front) |
4 ft 4 in (1.35 m) |
|
Extended platform (rear) |
4 ft 4 in (1.35 m) |
|
Length - Storage: Rails fixed |
15 ft 9 in (4.86 m) |
|
Width |
7 ft 5 in (2.3 m) |
|
Height - Storage: Folding Fence |
10 ft 6 in (3.24 m) |
|
Height - Fence Folded |
8 ft 1 in (2.47 m) |
|
Wheelbase |
9 ft 3 in (2.84 m) |
|
Ground clearance |
1 ft 2 in (0.36 m) |
|
Platform size(L*W*H) |
12 ft*6 ft 1 in*3 ft 6 in (3.75 m*1.86 m*1.1 m) |
|
Performance Data |
|
Platform Capacity |
2 |
|
Load capacity of platform |
1499 lbs (680 kg) |
|
Load capacity of extended platform |
500 lbs (227 kg) |
|
Driving speed (out of service) |
0¡«3.7 mph (6 km/h) |
|
Driving speed (in service) |
0¡«0.7 mph (1.1 km/h) |
|
Gradeability |
40% |
|
Inside turning radius |
12 ft 1 in (3.7 m) |
|
Outside turning radius |
19 ft (5.8 m) |
|
Up / down speed |
55 /49 s |
|
Control |
Proportional control |
|
Drive * steering |
4 WD * 2 WS |
|
Tire size/type |
33*12-20 /solid |
|
Engine |
|
|
Power source |
Perkins 404D - 22 (37KW) |
|
Volume of hydraulic oil tank |
140 L |
|
Volume of fuel tank |
110 L |
|
Weight |
|
Indoor & outdoor general |
18188 lbs (8250 kg) |
|
Standards compliant |
CE¡¢ISO¡¢GOST | |
|
|
|
|
|
|
