Safety & Stability:
¡ñMulti-function display: battery status, hour meter, error code etc.
¡ñThe application of hand brake and hydraulic brake improve the safety level of truck.
¡ñStep-less speed control.
¡ñEquipped with adjustable steering wheel, adapted to different operators.
¡ñAdvance linking system is designed with orienting and fixing bracket to the trailer.
¡ñLow noise.
Structural:
¡ñ¡±H¡± type axle design gives a good stability.
¡ñBatteries located in the lowest part of frame ensures tow tractor excellent stability because of low centre of gravity.
¡ñAutomatic reset make operation easier.
Serviceability:
¡ñCANbus technology reduces wiring complexity and increase reliability.
¡ñThe back cover is easy to open for maintenance and replacement of parts such as drive wheel, oil tube, accelerator, controller etc.
| Model |
|
EAQDD20 |
EAQDD30 |
EAQDD50 |
EAQDD60 |
EAQDD100 |
| Drive type |
|
Battery |
| Rated traction weight (60 minutes rated) |
kg |
2000 |
3000 |
5000 |
6000 |
10000 |
| Rated traction (60 minutes rated) |
N/kg |
500/50 |
750/75 |
1250/125 |
1500/150 |
500/50 |
| Max. traction (5 minutes rated) |
N/kg |
2000/200 |
3000/300 |
5000/500 |
6000/600 |
1000/1000 |
| Draw bar center height |
h1/h2(mm) |
280/350 |
280/350 |
280/350 |
280/350 |
320/400 |
| Weight |
kg |
930 |
980 |
1160 |
1280 |
1160 |
| Axle loading, front |
kg |
330 |
350 |
410 |
450 |
750 |
| Axle loading, rear |
kg |
600 |
630 |
750 |
830 |
1440 |
| Tyre number front/rear |
X=Driven wheels |
1/2 X |
1/2X |
1/2X |
1/2X |
2/2X |
| Tyre size, front |
solid rubber |
15*4 1/2-8 |
15*4 1/2-8 |
15*4 1/2-8 |
15*4 1/2-8 |
15.00-8-10PR |
| Tyre size, rear |
solid rubber |
15*4 1/2-8 |
15*4 1/2-8 |
4.00-8 |
4.00-8 |
6.50-10-12PR |
| Rear hanging distance |
L2(mm) |
350 |
350 |
450 |
450 |
600 |
| Seat height |
h3(mm) |
850 |
850 |
910 |
910 |
1050 |
| Overall length |
L (mm) |
1720 |
1720 |
1940 |
1940 |
2485 |
| Overall width |
W(mm) |
970 |
970 |
1100 |
1100 |
1160 |
| Overall height |
H(mm) |
1250 |
1250 |
1250 |
1250 |
1480 |
| Min. ground height |
X(mm) |
100 |
100 |
100 |
100 |
138 |
| Min. turning radius |
Wa(mm) |
1519 |
1519 |
1650 |
1650 |
2200 |
| Travel speed, laden |
km/h |
8 |
7 |
8 |
7 |
6.5 |
| Travel speed, unladen |
km/h |
13 |
13 |
14 |
14 |
7 |
| Battery volts./ Cap. |
v/ah |
48/240 |
48/270 |
48/360 |
48/400 |
48/500 |
| Battery weight |
kg |
350 |
400 |
530 |
610 |
950 |
| Traction bolt |
|
Traction bolt | |
